As most of you will know I have spent a lot of time mucking about with PMR446 radios over the years, indeed I remember buying my first pair of Goodman’s Trackers back in 1999!!!!

PMR446 can be fun, trying to get the most out of the small amount of power and tiny antennas, and as my world record contact in 2003 into Holland from the North East of England shows (LINK) you really can get some amazing distances on standard equipment. However some people do like to mod their radios and one of the simplest mods is to attach an external dipole antenna. This is what you will see in this interesting video.

One thing that puzzles me about this video… take a note of the frequency on the guys receiver when he is testing his PMR446 radio on CHANNEL 4…….?????????
If you would like more information on PMR446 see my archived website HERE which has lots of information about long distance contacts and mods to PMR446 radios.
Share on Google+Tweet about this on TwitterShare on FacebookPrint this pageShare on LinkedIn

The 10th SpaceX International Space Station cargo resupply mission delivered investigations to study human health, Earth science, and weather patterns last Thursday. It also carried a new Ericsson 2-meter handheld radio to replace one that failed a few months ago, disrupting the Amateur Radio on the International Space Station (ARISS) program. The VHF radio in the Columbus module was used for school group contacts and for Amateur Radio packet, temporarily relocated to UHF after the VHF radio failure. ARISS International Chair Frank Bauer, KA3HDO, said the just-arrived Ericsson radio will, at some point, be installed in Columbus, replacing the Ericsson UHF radio now supporting APRS packet and some school contacts. Bauer made it clear that the new Ericsson transceiver is an interim measure for ARISS.

“ARISS is making great progress on the development of the new interoperable radio system that we hope to use to replace our aging radio infrastructure in the Columbus module and the Service module,” he said. “The hard — and expensive — part of this effort is just beginning, with testing and human [spaceflight] certification on the horizon.” ARISS was able to shift school contacts from NA1SS to the Kenwood TM-D710 transceiver in the Russian Service Module. Cosmonauts use that radio to carry out their ARISS school contacts from RS0ISS.

Bauer thanked all of ARISS’s partners, which include ARRL and AMSAT, as well as individuals and entities that have donated to the program. In December, ARISS announced a “notable contribution” from the Quarter Century Wireless Association (QCWA) to help support development and certification of new ISS radio hardware.

The Ericsson MP-A VHF handheld that ISS crew members had used to speak via Amateur Radio with students and educational groups around the world for more than 16 years began displaying an error message last fall, rendering it unusable. ARISS has said ARISS’s new JVC Kenwood TM-D710GA-based radio system, once on station and installed, will improve communication capability for students scheduled to participate in educational contacts and related activities. The new system also will allow greater interoperability between the Columbus module and the Russian Service Module.

In 2015, ARISS kicked off its first fundraising program, after having relied on support from NASA, ARRL, AMSAT, and individual donors and volunteers to cover the costs of day-to-day operations and spaceflight equipment certification. NASA budget cutbacks made it less certain that ARISS would be able to cover its operational expenses going forward. ARISS leadership initiated the fundraising effort with the goal of securing greater financial stability. TheARISS website has more information on how to support the program. — Thanks to AMSAT News Service, ARISS

Source:ARRL

News

Review

Equipment

EXPERIMENTAL SWRX

EXPERIMENTAL SWRX

January 26, 2017
No comments

The Stampfl receiver is still in its experimental stadium and is not, comparable to a KWZ-30, Reuter or Perseus receiver. But an Assembly kit for the… Read more



Share on Google+Tweet about this on TwitterShare on FacebookPrint this pageShare on LinkedIn

Showing how the OM-Power Automatic amplifiers like the OM-2500A, OM-4000A, can control the selection of up to ten antennas driving an antenna switch and up to ten filters. A Vector Network Analyzer, Array Solutions’ VNA UHF is plotting the S21 (Filters Insertion Loss) continually.



The OM2500A linear amplifier is designed for all short wave amateur bands from 1.8 to 29.7 MHz (including WARC – bands ) and all modes. It is equipped with the ceramic tetrode FU-728F.



The advantages of OM2500A:

  • Automatic switching between bands
  • Automatic tuning with the band according to segments
  • Automatic switching of band pass filter
  • Automatic switching of the antenna switch
  • The possibility to use 2 different antennas within one band or segment
  • Full compatibility with
    • – ICOM
    • – YEASU
    • – ELECRAFT
    • – Ten-Tec Orion
    • – Kenwood
    • – Icom transceiver protocol using by microHAM devices, CI-V output (MK II, MK2R, MK2R+, etc)

 Specifications of the OM-2500A:

Frequency coverage:                     Amateur bands 1.8 – 29.7 MHz including WARC

Power output:                                     2500 W in SSB and CW

                                                            2000 W in RTTY, AM and FM

Driver Power:                                     60 to 80 W for full Output Power

Input impedance:                             50 Ohm VSWR < 1.5 : 1

Output amplification:                     15 dB

Output impedance:                             50 Ohm unbalanced

Maximum output SWR:                     2:1

SWR protection:                             Automatic switching to STBY , when reflected power is 350 W or higher



Intermodulation distortion:             32 dB below nominal output

Suppression of harmonics:             < -50 dBc

Tube:                                             FU-728F Ceramic tetrode

Cooler:                                             Centrifugal blower + axial blower

Power supply:                                      2 x configurable for 220, 230 or 240 V AC – 60 Hz one or two phases

Transformers:                                     Two  toroidal transformers 2.0 kVA each

Protection circuits:                             – SWR too high

                                                      – Anode current too high

                                                      – Screen current too high

                                                      – Grid current too high

                                                      – Mistuning of the power amplifier

                                                      – Soft start for protecting your fuses

                                                      – “Switch –on blocking“ at top cover removal

Bar graph indications:                     – Power output – bargraph 50 LED

                                                      – Reflected power – bargraph 20 LED

                                                      – Current at screen ( Ig2 – bar graph 10 LED )

                                                      – Anode voltage, anode current, tuning – bargraph 30 LED

LED indicators:                             – Control grid current ( Ig1 – 2 LED )

                                                      – WAIT – Preheating of tube (180 sec )

                                                      – STBY– Standby

                                                      – OPR – Operating condition

                                                      – FAULT – failure, switching off for about 4 seconds

                                                      – Inhibit – operating condition

                                                      – ANT 1 – which antenna is in use

                                                      – ANT 2 – which antenna is in use

                                                      – UP – DWN – Listing in menu

                                                       – MAN – Manual operating

                                                       – AUTO – Automatic operating

                                                       – TUNE – Tuning

                                                       – ANT – Antenna selection

Parameters:                                      485 mm (19.1″) W x 200 mm (7.9″) H x 455 mm (17.9″) D

Weight:                                              40 kg (88 lb)
